HOME ENTERTAINMENT -  MODEL 22 RADIO

Type:   9 tube TRF set with AVC
Circa:  August 1930
Tube Lineup : 1x UX280; 3 x UY224; 3 x UY 227;  2x UX245
Power Input :  AC operated.  115VAC , 25 or 60Hz
Original List Price: $285
Cabinet: Console
Link for Model 22 schematic

Comment: Also known as the  "Senior"


Model 22



Looking for a Model 22 photo. Contact:  jerry.proc@sympatico.ca



Credits and References:

1) Canadian Marconi Service Manual Vol. 1
2) The Early Development of Radio in Canada 1901 to 1930 by Robert Murray
3) Lewis Bodkin  <05bodkin555(at)gmail.com>
