CANADIAN MARCONI HOME ENTERTAINMENT -  MODEL 120

Type: 15 tube, AC powered, double conversion superheterodyne receiver with automatic frequency control. and wide/narrow selectivity.

Frequency range:

525 to 1630 KHz
5930 to 6220 KHz
9380 to 9720 KHz
11650 to 11970 KHz
15040 to 15450 KHz
17620 to 18030 KHz

Selectivity: Wide - 35 KHz; Narrow - 19 KHz

Tube lineup:  6G5, 6K7, 6L7, 6J5, 6A8, 2 x 6K7, 6H6 , 6F5, 6J7, 6C5, 2 x 6L6, 2 x 5Y4
Audio power:  18 watts
Speaker: 12 in dynamic

Input power:

115 VAC 60 Hz 150 watts
115 VAC 25 Hz 152 watts

Model 120 image courtesy Radiomuseum.org.
Chassis- top view.

Contributors or References:

1) Canadian Marconi Service Manual - Volume 1
