CANADIAN MARCONI HOME ENTERTAINMENT -
MODEL 190

Type: 10 tube, AC superheterodyne receiver with a 14 pushbutton controls. .

Frequency range:

540 to 1520 KHz
5950 to 6250 KHz
9450 to 9750 KHz
11650 to 11950 KHz
15050 to 15400 KHz

Tube lineup: 1851, 6SA7, 6SK7, 2 x 6SQ7, 6J6, 2 x 6F6, 5Y4, 6U5
Audio power: 4.5 watts
Speaker: 12 inch dynamic

Input power:

115 VAC 60 Hz 105 watts
115 VAC 25 Hz  108 (?) watts

Dimensions: ?


Image via Marconi service manual .Does anyone have an  actual photo of the Model 190 radio? Contact:  jerry proc@sympatico.ca

Contributors or References:

1) Canadian Marconi Service Manual - Volume 1
